Performing Cloud-side Distributed Inference Using Python Interface

Overview

For scenarios where large-scale neural network models have many parameters and cannot be fully loaded into a single device for inference, distributed inference can be performed using multiple devices. This tutorial describes how to perform MindSpore Lite cloud-side distributed inference using the Python interface. Cloud-side distributed inference is roughly the same process as Cloud-side single-card inference and can be cross-referenced. For the basic concept of distributed inference, please refer to MindSpore Distributed inference, and MindSpore Lite cloud-side distributed inference has more optimization for performance aspects.

MindSpore Lite cloud-side distributed inference is only supported to run in Linux environment deployments with Ascend 910 and Nvidia GPU as the supported device types. As shown in the figure below, the distributed inference is currently initiated by a multi-process approach, where each process corresponds to a Rank in the communication set, loading, compiling and executing the respective sliced model, with the same input data for each process.

Each process consists of the following main steps:

Model reading: Slice and export the distributed MindIR model via MindSpore. The number of MindIR models is the same as the number of devices for loading to each device for inference.
Context creation and configuration: Create and configure the Context, and hold the distributed inference parameters to guide distributed model compilation and model execution.
Model loading and compilation: Use the Model.build_from_file interface for model loading and model compilation. The model loading phase parses the file cache into a runtime model. The model compilation phase optimizes the front-end computational graph into a high-performance back-end computational graph. The process is time-consuming and it is recommended to compile once and inference multiple times.
Model input data padding.
Distributed inference execution: use the Model.predict interface for model distributed inference.
Model output data obtaining.
Multi-process execution of distributed inference programs.

Preparation

To download the cloud-side distributed inference python sample code, please select the device type: Ascend or GPU. The directory will be referred to later as the example code directory.
Slice and export the distributed MindIR model via MindSpore and store it to the sample code directory. For a quick experience, you can download the two sliced Matmul model files Matmul0.mindir, Matmul1.mindir.
For Ascend device type, get the group network information file (such as rank_ table_xxx.json) from Distributed parallel training base sample code. Alternatively, generate networking information files as needed through hccl_tools.py. Refer to the Distributed Parallel Training Basic Sample for configuration, and store it in the sample code directory, and fill in the path of the file into the configuration file config_file.ini in the sample code directory.
Download the MindSpore Lite cloud-side inference installation package mindspore-lite-{version}-linux-{arch}.whl, store it to the sample code directory, and install it via pip.

The main steps of MindSpore Lite cloud-side distributed inference will be described in the subsequent sections in conjunction with the code, and please refer to main.py in the sample code directory for the complete code.

Creating Contextual Configuration

The contextual configuration holds the required basic configuration parameters and distributed inference parameters to guide model compilation and model distributed execution. The following sample code demonstrates how to create a context through Context.

# init context
context = mslite.Context()

Ascend, Nvidia GPU are supported in distributed inference scenarios, and can be specified by Context.target to specify the device to run.

Configuring Ascend Device Context

When the device type is Ascend (Ascend910 is currently supported by distributed inference), set Context.target to Ascend and set DeviceID, RankID by the following way. Since Ascend provides multiple inference engine backends, currently only the ge backend supports distributed inference, and the Ascend inference engine backend is specified as ge by via ascend.provider.The sample code is as follows.

# set Ascend target and distributed info
context.target = ["Ascend"]
context.ascend.device_id = args.device_id
context.ascend.rank_id = args.rank_id
context.ascend.provider = "ge"

Configuring GPU Device Context

When the device type is GPU, set Context.target as gpu. The distributed inference multi-process application for GPU devices is pulled up by mpi, which automatically sets the RankID of each process, and the user only needs to specify CUDA_VISIBLE_DEVICES in the environment variable, without specifying the group information file. Therefore, the RankID of each process can be used as DeviceID. In addition, GPU also provides multiple inference engine backends. Currently only tensorrt backend supports distributed inference, and the GPU inference engine backend is specified as tensorrt by gpu.provider. The sample code is as follows.

# set GPU target and distributed info
context.target = ["gpu"]
context.gpu.device_id = context.gpu.rank_id
context.gpu.provider = "tensorrt"

Model Creation, Loading and Compilation

Consistent with MindSpore Lite Cloud-side Single Card Inference, the main entry point for distributed inference is the Model interface for model loading, compilation and execution. Create Model and call the Model.build_from_file interface to implement the model Loading and model compilation, the sample code is as follows.

# create Model and build Model
model = mslite.Model()
model.build_from_file(model_path, mslite.ModelType.MINDIR, context, args.config_file)

Model Input Data Padding

First, use the Model.get_inputs method to get all the input Tensor, and fill in the Host data through the related interface. The sample code is as follows.

# set model input as ones
inputs = model.get_inputs()
for input_i in inputs:
    input_i.set_data_from_numpy(np.ones(input_i.shape, dtype=np.float32))

MindSpore Lite input can also be constructed in the following way.

# np_inputs is a list or tuple of numpy array
inputs = [mslite.Tensor(np_input) for np_input in np_inputs]

Distributed Inference Execution

Call the Model.predict interface to perform distributed inference, with the following sample code.

# execute inference
outputs = model.predict(inputs)

Model Output Data Obtaining

The model output data is stored in the output Tensor defined in the previous step, and the output data can be accessed through the relevant interface. The following example code shows how to access the output data and print it.

# get output and print
for output in outputs:
    name = output.name.rstrip()
    data_size = output.data_size
    element_num = output.element_num
    print("tensor's name is:%s data size is:%s tensor elements num is:%s" %
          (name, data_size, element_num))
    data = output.get_data_to_numpy()
    data = data.flatten()
    print("output data is:", end=" ")
    for i in range(10):
        print(data[i], end=" ")
    print("")

Performing Distributed Inference Example

Start the distributed inference in the following multi-process manner. Please refer to run.sh in the sample code directory for the complete run command. When run successfully, the name, data size, number of elements and the first 10 elements of each output Tensor will be printed.

# for Ascend, run the executable file for each rank using shell commands
python3 ./ascend_ge_distributed.py --model_path=/your/path/to/Matmul0.mindir --device_id=0 --rank_id=0 --config_file=./config_file.ini &
python3 ./ascend_ge_distributed.py --model_path=/your/path/to/Matmul1.mindir --device_id=1 --rank_id=1 --config_file=./config_file.ini

# for GPU, run the executable file for each rank using mpi
RANK_SIZE=2
mpirun -n $RANK_SIZE python3 ./main.py --model_path=/your/path/to/Matmul.mindir
